Product Description
RST934 Cable Kit
The Times Microwave LMR-400 is a low loss braided coaxial cable.
This 10mm(3/8in) 50 Ohm coax cable has a stranded outer conductor and a bare copper center conductor.
The 100 percent foil and 88 percent coverage braided shield prevents loss.
Cable Kit basics:
Piece 1 of 2 pieces: 1 x 14m(45.9ft) LMR400 with TNC-Male to N-Female connectors.
Piece 2 of 2 Pieces: 1 x 1m(3.3ft) LMR240 with N-Male to TNC-Male connectors.
SPECIFICATIONS
LMR400 Cable Dia Size: 10mm(0.4in)
LMR240 Cable Dia: 6.0mm(0.24in)
Connectors: LMR400 TNC-Male>N-Female, LMR240 N-Male>TNC-Male
Shield 0% Foil 88% Braided
Insulation: Polyethylene Foam PE Jacket
Approximate Weight: 3kg (LMR400: 0.068 lb/ft 0.10 kg/m)
Bend Radius Installation: 25.4 mm(1.0in)
Bend Radius Repeated: 101.6 mm(4.0in)
LMR400 Ideal Cable Length: 9-17.5 m(29-58 feet)
Impedance: 50 Ohms
VOP.: 85%
Application and Benefits
Easy, user friendly installation cable routing.
The 1 meter fly lead can conveniently be used at antenna or terminal end
Made in Australia, Times Microwave Systems cable is the choice of Industry and premium quality.
