Product Description
952BRS Iridium Beam RapidSAT LBT Hands Free Portable Bag Phone
The purpose built RapidSAT LBT bag phone provides integrated antenna, data and power connections that makes it possible to keep all antenna cables and power permanently connected to the handset and allows for the bag to be ready at all times.
The Intelligent handset supplied with RapidSAT LBT bag phone supports both handsfree and privacy modes of operation automatically switching between either mode with the handset in or out of the cradle.
The flexibility of the RapidSAT LBT enables the unit to be easily transported between various vehicles, boats, machinery or aircraft and simply connects to the vehicle’s DC power source for in vehicle use or alternatively the optional battery back-up for away from vehicle use.
The system has been purpose built, securely located within a “Soft” rugged carry bag making it small / light and easy to carry.
It comes complete with DC charging lead, Cigarette Lighter Plug, AC plug pack and a magnetic mount antenna with 5 metres of cable attached.
APPLICATIONS
. Disaster Recovery
. Emergency Services
. Temporary Vehicle Installations
. Temporary Marine Use
. Back-up communications
. Rental Product
. Camping and exploration groups
. Remote Tour Groups
. Schools / Colleges / Universities
Optional Beam UPS Battery back-up(part# RST055) is NOT INCLUDED
Overview
RapidSAT LBT by Beam
Robust design and construction
Charges ready for use
Small, tough, and lightweight carry bag
Houses all required cables & antenna
Includes Magnetic Mount Antenna
Antenna complete with 5m of cable
Power button to control unit power usage
Carry handle and shoulder strap
Additional storage pockets
Convenient hands-free operation
Controller/Privacy handset
USB data Port
Integrated antenna connection
No moving parts
11-32V DC Input
Supports Voice & Data services
. Full duplex
Loud ring indications
Echo cancellation
Auxiliary & constant power
Optional Battery Pack
Fully Certified – Including ROHS
QUALITY
100% factory tested
Compliance: Iridium, RoHS, CE, and IEC60945
Tech Specs
9555RS Docking Station Kit, IRIDIUM RapidSAT9555 by Beam
IRIDIUM Network
9555 Handset: 1616 – 1625 MHz
Compressed Data: 10 – 12 kbps
Voice / Data Modulation: 2.4 kbps
Power Specifications
Power Input Voltage: 11 – 32 V DC @ 4-1A
Power Consumption (AMPS): 12 V DC – Stand by – incl handset: 0.48, Transmit – incl handset: 0.68
Power Consumption (AMPS): 24 V DC – Stand by – incl handset: 0.25, Transmit – incl handset: 0.35
Physical Specifications
Dimensions: 380L x 250W x 150D(15 x 9.8 x 5.9in)
Antenna Cable length: 5m (16.4 ft)
Power Input Cable length: 1m (3.3 ft)
Weight: 3.7kg(8.15lb) without optional part# RST055 battery, NOT included
Environmental
RapidSAT LBT Operating Range: -30 to 70C(-22 to 158F)
UPS Battery RST055 – NOT INCLUDED, Operating Range: -20 to 60C(-4 to 140F)
Storage: -25 to 60(-14 to 130F)
Humidity: <85% RH non-condensing
Connectors and Interfaces
Iridium Antenna: Fixed cable to TNC-Male Connector
Power Input: 4W Molex Connector
Data Port: USB
Speaker: 3W
Certifications
Iridium: CE, RoHS
EMC Compliance: IEC/EN60945 (9 & 10)
Electrical Safety: IEC/EN/AS/NZ60950-1
